Sensors

Temperature, Humidity, Radar.

Display

480 × 480 pixels, 4-inch diameter

Operating voltage

24VAC~

Current

Maximm 2.5A total, Maximum 1.0A single output

Wi-Fi

Wi-Fi IEEE 802.11 a/b/g/n/ac 2.4 GHz/5 GHz, Zigbee, Thread, Bluetooth

Dimensions

3.94 × 3.94 × 0.98 in. (100 x 100 x 25 mm)

Temperature Sensitivity

±1°F (±0.5°C)

Humidity Sensitivity

±1%

Compatibility and Installation

The Thermostat Hub W200 is compatible with 24V HVAC systems and works with furnaces, ACs (2H/2C), heat pumps (2H/2C + 2-stage AUX), boilers, PTACs, and fan coil units (3 fan speeds). The Aqara Thermostat Hub W200 is NOT compatible if your system has any of the following terminals: 1, 2, 3, 4 A, B, C, D Water or H2O L1, L2, 110, 120, 240 Volts

Configuration and Binding

To bind other devices to the Thermostat Hub W200, please 1) Add the required "Screen Layout" in "My Screen" on the device details page in the Aqara Home APP. 2) Press on the corresponding screen layout, press the "+" sign to configure the required devices, scenes, services, etc. To link the Aqara G410 doorbell to the Thermostat Hub W200, first, 1) add your Aqara doorbell or door lock to your account. 2) Go to the Thermostat Hub W200 device details page, scroll down to find "Screen Configuration", and add the associated doorbell event push. 3) Select the associated doorbell and door lock.

Warranty

1 Year

Colour

Black
